Linksys E2000 Configuration Guide

Revision 1.1 Page 3
®®
Table of Contents
1 Introduction ........................................................................................................................... 4
2 Configuring the WiFi/Router .................................................................................................. 6
2.1 Connecting to the WiFi/Router ................................................................................. 6
2.2 Adding an IPG100 to the Network. ........................................................................... 9
2.3 Adding a PC based N2KServer
®
to the Network. ................................................... 12
2.4 Adding a MBB100 N2KView Client to the Network ................................................. 14
2.5 Adding a DSM800 N2KView Client to the Network ................................................ 15
2.6 Adding a Wired PC N2KView Client to the Network ............................................... 15
2.7 Adding a Wireless PC N2KView Client to the Network ........................................... 16
2.8 Adding a Mobile N2KView Client to the Network .................................................... 16
3 Resetting the WiFi/Router to Maretron Configuration .......................................................... 17
3.1 Physically Reset the WiFi/Router ........................................................................... 17
3.2 Give your Wireless Network a name ...................................................................... 17
3.3 Programming network security ............................................................................... 18
Appendix A- Client/Server Architecture ............................................................................. 19
A.1 Examples of NMEA 2000® Client/Server Architectures ......................................... 20
A.2 TCP/IP Networks .................................................................................................... 21
A.3 NAT (Network Address Translation) ....................................................................... 22
A.4 PAT (Port Address Translation) .............................................................................. 22
A.5 Static and Dynamic IP Addressing ......................................................................... 23
A.6 Software Firewall Configuration .............................................................................. 23
A.7 Data Security and Encryption ................................................................................. 23
Table of Figures
Figure 1 - Typical WiFi/Router Connection ................................................................................ 4
Figure 2 – LAN Client/Server Architecture Example with USB100 .......................................... 20

Linksys E2000 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Input current	1 A
Input voltage	12 V
Dimensions (WxDxH)	202 x 34 x 160 mm
WLAN data transfer rates supported	300 Mbit/s
DHCP client	-
Antennas quantity	3
Antenna gain level (max)	2.2 dBi
Web-based management	No
Security algorithms	WEP, WPA, WPA2
Certification	FCC, CE, IC-03, Wi-Fi
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	300 g
