Linksys E2000 Configuration Guide

Linksys® E2000 Wireless-N Router Configuration Guide
Page 24 Revision 1.1
The N2KView
®
system protects your vessel’s data with multiple levels of protection.
First, any data that passes between the N2KServer
®
server component and any N2KView
®
station components is protected using industry-standard SSL encryption. This encryption
standard is widely used to protect financial information on the internet. Each communication
session negotiates a random encryption key every time a connection is established. This
makes the data secure over public and private Wi-Fi networks, as well as the internet.
Second, each N2KView
®
station that wishes to connect to an N2KServer
®
server component
must authenticate itself by means of a server password. The server password is transmitted
by the N2KView
®
station to the N2KServer
®
server over the encrypted communication link.
The N2KServer
®
compares the server password to the one it was programmed with. Only if
the server password received from the station matches the server’s stored password is the
station granted access to the NMEA 2000 network data.
Third, access to the Router itself can be protected through passwords and the data flowing
through the router over wireless connections can be encrypted (scrambled) using a pass
phase.

Linksys E2000 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Input current	1 A
Input voltage	12 V
Dimensions (WxDxH)	202 x 34 x 160 mm
WLAN data transfer rates supported	300 Mbit/s
DHCP client	-
Antennas quantity	3
Antenna gain level (max)	2.2 dBi
Web-based management	No
Security algorithms	WEP, WPA, WPA2
Certification	FCC, CE, IC-03, Wi-Fi
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	300 g
