Linksys X1000 User Manual

16
Advanced Configuration
Linksys X1000
WPA2 Enterprise
This option features WPA2 used in coordination with a RADIUS server. (This
should only be used when a RADIUS server is connected to the router.)
NOTE
If you select WPA2 Enterprise as your Security Mode, each device
in your wireless network MUST use WPA2 Enterprise and the same
shared key.
RADIUS Server Enter the IP address of the RADIUS server.
RADIUS Port Enter the port number of the RADIUS server. The default is 1812.
Shared Key Enter the key shared between the router and the server.
WPA Enterprise
This option features WPA used in coordination with a RADIUS server. (This
should only be used when a RADIUS server is connected to the router.)
NOTE
If you select WPA Enterprise as your Security Mode, each device
in your wireless network MUST use WPA Enterprise and the same
shared key.
RADIUS Server Enter the IP address of the RADIUS server.
RADIUS Port Enter the port number of the RADIUS server. The default is 1812.
Shared Key Enter the key shared between the router and the server.
WEP
WEP is a basic encryption method, which is not as secure as WPA.
NOTE
If you select WEP as your Security Mode, each device in your
wireless network MUST use WEP and the same encryption and
shared key.
Encryption Select a level of WEP encryption, (40/64-bit 10 hex digits) or
104/128-bit (26 hex digits). The default is 40/64-bit (10 hex digits).
Passphrase Enter a passphrase to automatically generate the WEP key. Then
click Generate.
Key 1 If you did not enter a passphrase, enter the WEP key manually.

Linksys X1000 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11n
Rack mounting	No
Frequency band	2.4 GHz
WLAN data transfer rates supported	300 Mbit/s
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	3
DHCP client	-
Supported network protocols	IPv6
Antennas quantity	2
Security algorithms	WPA2
Product color	Black
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Weight	- g
