KLIMAX
Loudspeaker System
Owner’s Manual
English Klimax 345
CConnecting
IMPORTANT:
Do not turn on the mains supply until you have connected all other components.
Once all the other connections have been made, connect the Klimax 345 loudspeaker to
a mains supply using the mains lead provided.
Connecting to an AV processor
Connecting to a stereo pre-amplifier
if used with large (full-range frequency response)
loudspeakers (for example Klimax 350 or 320).
Connecting to a stereo pre-amplifier and power amplifier
if used with small (limited bass
response) loudspeakers.
Note:
In the above configuration the Klimax 345 loudspeaker is being used to stop low bass
notes from being sent to the main loudspeakers.
Connecting to another Klimax 345 lo
udspeaker
KLIMAX 345 - ONE
KLIMAX 345 - TWO
KLIMAX 345 - ONE
KLIMAX 345 - TWO
O
OR
