12
AV (COMPOSITE VIDEO) CONNECTION
YPbPr CONNECTION
For basic connection, use the
composite Audio L/R (white/red) and
CVBS (yellow) cable to connect the
unit with other devices.
AV cable
(Not included)
Audio L/R of AV Cable
(Not Included)
YPbPr cable
(Not included)
Adaptor cable for
Mini AV
(Included)
Adaptor cable
for Mini AV
(Included)
Adaptor cable
for Mini YPbPr
(Included)
