13
Emergency Response Guide
DANGER
ALWAYS assume the high voltage is active.
Follow the procedure to disable the high voltage, even if the
crash safety detector appears to have been triggered.
// CRASH SAFETY IMPACT DETECTOR
Crash safety impact detector
For the safety reasons, the high-voltage safety disconnect
switch is linked to the ’s impact sensor. When the
sensor reads an impact between 8 g and 30 g, it will instantly
deactivate the high-voltage circuits.
Figure 12 ― Location of impact sensor
