22
Figure 25 ― Cabin’s storage compartment under the passenger seat
Figure 26 ― Tow hooks inserted on the front crossmember
3. Insert the two hooks on the front cross member.
4. Secure both tow hooks with a dowel and a cutter pin.
// TOWING THE VEHICLE
Removing wheel axle half shaft
When performing front lift towing at a speed over 35 mph
(50 km/h), a wheel axle half shaft must be removed from each
rear wheel to avoid damaging the electric motor components.
In this case, be sure to cover the shaft opening to avoid
contaminating the oil.
Figure 27 ― Wheel axle half shaft
