LION 6 - High-Voltage Cable Routing

7
Emergency Response Guide
// HIGH-VOLTAGE COMPONENTS
Figure 1 ―
Table 1 ― Identification of
high-voltage components
Nº Identification Nº Identification Nº Identification Nº Identification
1
AC compressor
5
DC junction box
8
DCDC converter
(2 units)
11
BTMS compressor
(battery thermal
management system)
2
Electric defroster/heater
6
Air brake compressor
3
Charging port
7
High-voltage distribution
unit (HVDU)
9
BCI20 (charger inverter)
12
Motor
4
Hydraulic pump
10
Batteries (Lithium-Ion)
13
Drive
Figure 4 ― Identification of high-voltage components (top view)
