LION SG4000 User Manual

SMOKE GENERATOR
8
WWW.LIONPROTECTS.COM
A FLUID LEVEL SENSOR
This bar indicates the remaining Smoke Liquid in the tank.
B HEATER CORE TEMPERATURE
This number indicates the heater core temperature as a percentage. One
hundred percent indicates 660°F (350°C). When operating normally, the
system will range between 96 and 103 percent.
C CURRENT OPERATING MODE
This section displays the current activity status of the Smoke Generator. In this
image, the machine is ready to produce smoke but is not actively generating
any, as shown by displaying “Ready”. During warm up, it will display “Heating”.
FIGURE 2: DISPLAY SCREEN CLOSE UP
A
B C
D
E
G
F
