Wiring your #154 Railroad Crossing Flasher to a power source
Y
our #154 Railroad Crossing Flasher operates best at 12-18 volts (AC). Have an adult strip
1⁄4" of insulation from the ends of the three wires included with the #154 Railroad Crossing
Flasher, if they have not already been stripped.
Only an adult should perform this task. Always use care when stripping wires.
Attach one wire to each terminal post on the base of the accessory. Connect the ends of the
wires to the #153C Contactor and transformer as shown in Figure 2 below.
To connect a wire to the Contactor’s spring clips, press down the upper half of the spring clip
terminal until the lower part projects through the slot. Insert the bare wire end into the loop,
then release the upper part of the clip. Spring tension will hold the wire tight.
This accessory will also operate using an insulated track section (available
separately).
4
Note!
Caution!
