20
Maintaining and servicing your set
D
uring the course of normal operation, the lamp inside your caboose may require replacement.
Follow these steps and refer to Figure 12 on page 21.
1. Lift off the roof from the window shell and body.
2. Pull out the end frame tab from the slot formed by the caboose body and roof. The end frames
are hinged at the platform to swing outward, away from the body.
3. Remove the window shell. To remove the window shell, carefully bend the sides of the caboose
outward while pulling up on the window shell until the tabs are released from the windows.
4. Pull the lamp straight up and out of the socket. Replace it with Lionel lamp no. 630-8352-311,
available at your authorized Lionel Service Center or Lionel Service.
5. Lower the window shell back into the body, making sure that the tabs snap into the windows.
6. Reposition the roof above the window shell and body, fit the tabs on the end frames into the cor-
responding slots in the body, and press down the roof to secure the end frame tabs.
Replacing your square window caboose lamp
