7
Operating the Uncoupling Track section
W
ithout making any additional connections, your Uncoupling Track is powered through
track power. Be sure that your throttle is set to 10-12 volts (AC) to activate the magnet.
To uncouple or operate your rolling stock, position the trigger disc over the central magnet,
press the button on the controller, and the magnet will pull the trigger disc downward to release
the coupler or activate the car. Refer to Figure 5.
Do not exceed ten seconds when pressing the button. Holding down the button for
over ten seconds may damage the track section.
Figure 5. Central magnet
Caution!
Central
magnet
