Lippert Components OCTP - Slide-out Operation; Stabilizer Control

Rev: 12.21.18 Page 8
CCD-0001440
11. Slides, if equipped:
A. Pressing the Slides icon (Fig. 2) will allow you to access the slide-out control screen (Fig. 15).
B. Select a slide-out to operate.
I. Pressing OUT will extend the slide-out (Fig. 15A).
II. Pressing IN will retract the slide-out (Fig. 15B).
12. Stabilizers, if equipped:
A. Pressing the Rear Stabilizer icon (Fig. 2) will allow you to access the rear stabilizer control
screen (Fig. 16).
B. Select a stabilizer to operate.
I. To extend the rear stabilizer, press the EXTEND button (Fig. 16A).
II. To retract the rear stabilizer, press the RETRACT button (Fig. 16B).
A
Fig. 15
B
A
Fig. 16
B
