Rev: 05.24.2016
Page 7
Slim Rack Slide-out Manual
Operation
Always make sure that the slide-out room path is clear of people and objects
before and during operation of the slide-out room. Always keep away from the
slide rails when the room is being operated. The gear assembly may pinch or
catch on loose clothing causing personal injury.
Prior To Moving the Slide-Out Room:
• Make sure the engine or generator is running to ensure ample voltage is being supplied to the slide-out
control box.
• Set the parking brake, if applicable.
Extending the Room
1. The engine or generator must be running, or coach must be plugged into shore power.
2. Transmission must be in park or neutral (if applicable).
3. Set the park brake (if applicable) and level the unit.
4. If equipped, remove the transit bars.
5. If equipped, turn “on” the on/off switch or key.
6. Press and hold the OUT button (Fig. 8A). There will be a slight delay before the room will begin to
move. This is normal.
7. Release the button when the room is fully extended and stops moving.
8. If equipped, turn “off” the on/off switch or key.
Retracting the Room
1. The engine or generator must be running, or the coach must be plugged into shore power.
2. Transmission must be in park or neutral (if applicable).
3. Set the park brake (if applicable) and level the unit.
4. If equipped, turn “on” the on/off switch or key.
5. Press and hold the IN button (Fig. 8B). There will be a slight delay before the room will begin to move,
this is normal.
6. Release the button when the room is fully retracted and stops moving.
7. If equipped, turn “off” the on/off switch or key.
8. If equipped, install the transit bars.
Preventative Maintenance
Your Power Gear slide-out system has been designed to require very little maintenance. To ensure the long
life of your slide-out system, read and follow these few simple procedures:
• When the room is extended, visually inspect the slide rail assemblies. Check for excess build up of dirt or
other foreign material. Remove any debris that may be present.
• If the system squeaks or makes any noises, blow out any debris from the gear rack arms and apply a dry
lubricant to prevent and/or stop squeaking.
