Smart Jack
™
model no. 643589
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001304lci1.com 574-537-8900 Rev: 04.18.18
Parts List Preparation
1. Remove the Smart Jack foot pad from the Smart Jack
(if necessary).
A. Remove the snapper pin (Fig.1B), which holds the foot
pad (Fig.1C) to the jack leg (Fig.1A). Set the snapper pin
and the foot pad to the side.
2. Support the trailer according to OEM instructions.
Fig.1
A
B
C
Part# Description
431423 Smart Jack with Foot Pad (AM)
405217 Adjustable 9” Inner Foot Pad Kit
116112 Scissor Jack Crank Handle
Smart Jack
™
model no. 643589
Installation and Owner’s Manual
(For Aftermarket Applications)
