lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc
®
AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
5. Tap the readout button (Fig.20A) of a tyre to launch its
properties window� Within the selected tyre’s properties
window, various tyre and sensor specications can be
observed and altered�
A. Last data received posts the date and time the app
last received tyre monitoring system information�
B. Pressure posts the currently-sensed pressure of
the selected tyre�
C. Temperature posts the currently-sensed
temperature of the selected tyre�
D. Battery Level posts the current battery voltage of
the sensor’s battery�
Fig.20
A
UNDER OR OVER PRESSURIZED TYRES CAN
CAUSE UNFORESEEN, DETRIMENTAL EFFECTS
ON TYRES AND UNIT, INCLUDING UNDESIRABLE
TREAD WEAR. TYRES SHOULD ALWAYS BE
PRESSURIZED TO WITHIN THE MANUFACTURER’S
RECOMMENDATIONS.
E. Minimum/Maximum Pressure Threshold posts
the currently programmed minimum and maximum
pressure limits for the selected tyre�
F. Maximum Temperature Threshold posts the
currently programmed maximum temperature limit for the
selected tyre�
G. Maximum Temperature Change posts the
currently programmed maximum +/- temperature change
limit for the selected tyre�
Tyre Limits Example
Programmable tyre limits have a “next” arrow (>)
that, when tapped, opens that feature’s scrollable window
of available settings� Scroll through the limits window to
find the desired setting, select it, then tap the “back” arrow
(<) (Fig.21A) located above the tyre’s name at the top of the
window’s heading�
To Next Page
