Lippert Tire Linc - Sensor Pairing Sequence

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc
®
AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
front
rear
Stem Sensor Pairing Sequence
The pairing sequence for stem sensors (Fig.13) is
as follows:
1. SINGLE AXLE: Stem sensors for a single-axle caravan
MUST be paired in the following order: Left front (Fig.14A),
right front (Fig.14C)�
2. DOUBLE AXLE: Stem sensors for a double-axle
caravan MUST be paired in the following order: Left
front (Fig.14A), left rear (Fig.14B), right front (Fig.14C), right
rear (Fig.14D)�
11. Finish setup by tapping the arrow to the right of Learn
Sensors (Fig.12A)�
NOTE: Users must scroll down the screen in order to view
the Learn Sensors option at the bottom of the page�
Fig.12
A
Fig.14
Fig.13
A
B
C
D
