8
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc
®
AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Use Smart Phone to Pair Sensors to Repeater
NOTE: If a wrong caravan type is chosen or there is a new
caravan configuration, see Troubleshooting section for
factory reset�
The OneControl BT app on the smart phone will indicate
in specific order which tyre the stem sensor cap should be
installed: Front Left, Rear Left, Front Right, Rear Right, etc�
1. Have stem sensors (Fig.13) available to install on the tyre
stems and remove any existing stem caps from the tyres�
NOTE: If using the lock nuts as a theft deterrent, add the
lock nuts to the tyre stems but make sure there is room to
add the sensors� Lock nuts will be tightened later� The lock
nuts are optional and are not required to be installed�
2. Pair stem sensors to the repeater as follows:
A. Select the Learn Sensors arrow (Fig.15A) in the TYRE
PRESSURE app screen if not having done so already� The
app will display a list of tyres with instructions to screw the
first stem sensor onto the Front Left tyre stem (Fig.16)�
B. Install a stem sensor onto the tyre stem in the proper
sequence (Fig.16) and wait for the smart phone to indicate
the sensor was found (Fig.17A)�
NOTE: It may take up to 90 seconds for the sensor to
awake and be found�
C. If the sensor is not seen within 90 seconds, unscrew the
sensor from the tyre stem, wait approximately 10 seconds
and then reinstall the sensor� Do not proceed to install any
other sensors until the app shows the sensor found�
D. After the sensor has been found, the app will indicate
the next tyre sensor to be paired (Fig.17B)�
3. Repeat steps 2B, 2C and 2D until all sensors are
learned (Fig.18)�
Fig.15
Fig.16
A
