6 7
DIMENSIONS
Side
Top
FronT
rear
LectroCount LCR 600
Ø7.5"
13"
4.72"
9.9"
70°
8.13"
10.7"
Tapped for Ground Screw
½" NPT Ports (5)
Holes for Weights
& Measures Seal
¾" NPT Ports (2)
The equipment is Listed by UL to applicable US and Canadian standards for use in hazardous locations under Liquid Controls le
E180172
CLASS I
Potentially Explosive Gas/Vapor Atmospheres
DIVISION 2
Gases and vapor are not normally present in an explosive concentration but may accidentally exist during abnormal operations
GROUPS C & D
Flammable/explosive Gas groups
T6
Temperature class for surface temperature limitations. T6 is ≤ 85º C
amb
Safe limits of ambient temperature
IP66 AND NEMA 4
Ingress protection: dust tight and protected against powerful water jetting
Consult factory for current compliance status.
SAFETY MARKINGS
