M & MA Series Meters

Get the latest PDF manual:

https://www.lcmeter.com/resources/technical/manuals

Mobile/online version of this manual:

https://www.lcmeter.com/manuals

NOTE: MA-4®, M-5®, and MA-5® old style models, M-60® and M-80® current models

have a driven reduction gear attached by a shoulder bolt in the center of the front.

4. Inspect and clean all critical surfaces: gear teeth, rotors, and internal housing faces.

5. Remove any crystalline formations using fine emery cloth or a fine wire brush.

6. Remove nicks and burrs on metal parts with a stone.

7. Remove all grit and other foreign particles.

8. Replace all parts that appear worn or damaged.

Reassembling the Meter

Reassembling the Meter includes the following:

Reassembling the bearing plates and rotors

Timing the rotor gears

Completing meter reassembly

These charts are also available near the end of this topic:

Torque Chart

Wrench and Socket Size Chart

Reassembling the bearing plates and rotors

Follow this procedure to reassemble the Meter:

1. Replace the non-rotor gear bearing plate to the housing with the bearing plate screws.

NOTE: The rotor gears are on the rear bearing plate of MA-4®, M-5®, and MA-5® old

style models, M-60® and M-80® current models. On all other models, the rotor gears

are on the front bearing
