Z-178

1,65 m

Z-178/2

1,85 m

Z-178/1

1,35 m

Z-178/1

(60)

1,35 m

Z-178/1

(80)

1,35 m

Z-178/3

2,10 m

V-belt SPA 2932 5-178-020-452 4 - - - - -

V-belt SPA 3150 5-178-020-452/2 - 4 - - - -

V-belt SPA 2832 5-178-020-185 - - 3 - - -

V-belt SPA 2120 5-178-020-185/60 - - - 3 - -

V-belt SPA 2482 5-178-020-185/80 - - - - 3 -

V-belt SPA 3650 5-178-020-452/3 - - - - - 4

23 Cover plate 5-178-020-465 1 1 1 1 1 1

Pin Ø18x60 5-178-020-478 1 1 1 1 1 1

5-178-020-500 1 - 1 1 1 -

5-178-020-500/2 - 1 - - - 1

5-178-020-684 1 - 1 1 1 -

5-178-020-684/2 - 1 - - - -

5-178-020-684/3 - - - - - 1

5-178-020-602 1 - 1 1 1 -

5-178-020-602/2 - 1 - - - -

5-178-020-602/3 - - - - - 1

29 Sealing ring 5-178-020-615 1 1 1 1 1 1

30 Plastic guard 21903 1 1 1 1 1 1

Ball bearing 6009-2RS PN-85/M-86100 1 2 1 1 1 -

Ball bearing 6207-2RS PN-85/M-86100 - - - - - 2

32 Ball bearing 6206-2RS PN-85/M-86100 1 2 1 1 1 -

Ball bearing 6007-2RS PN-85/M-86100 1 2 1 1 1 -

Ball bearing 6207-2RS PN-85/M-86100 - - - - - 1

Parallel key A8x7x56 PN-70/M-85005 1 1 1 1 1 -

Parallel key A10x9x65 PN-70/M-85005 - - - - - 1

35 Spring retaining ring Z35 PN-81/M-85111 1 1 1 1 1 1

36 Spring retaining ring W75 PN-81/M-85111 1 1 1 1 1 -

37 Spring retaining ring Z45 PN-81/M-85111 1 1 1 1 1 -

Spring retaining ring Z30 PN-81/M-85111 1 1 1 1 1 -

Spring retaining ring Z35 PN-81/M-85111 - - - - - 1

39 Washer 17 PN-78/M-82006 1 1 1 1 1 -

Tightener spring

Part number or standard

Remarks

Quantity

Item no.

in Fig.

Part name

Driving head tube, set

Head shaft

Table 3. continued.
