Designing a System
To double the radiator power, it is possible to vertically or horizontally mount two radiators together using the
LA-342 Dual Radiator Mounting Bracket (sold separately). This is highly recommended in larger rooms.
RAD 1
RAD 2
3B
It is critical to mount the radiators at the proper height. If the radiator is mounted too low, the coverage pattern
will be too small to provide sucient long throw coverage. If the radiator is mounted too high the required angle
of the radiator will cause the radiation pattern to be compromised. The best height of the radiator is about 16 ft
2
(5 m
2
) from the oor.
Height of Radiators
3C
The mounting system for Listen Technologies LA-140 radiators allow you to mount the radiator in 15 degree
increments. The best angle depends on the shape of the room and the orientation of the radiator to the seats
within the room. In general, mounting angles of 15 and 30 degrees provide the best coverage.
Radiator Mounting Angle
