Lite-on Tech NA120 - Connectors and Headers; Front Side USB Connector

NA120 Motherboard
15
Jumper Introduction
cont….
Connectors and Headers
Front Side USB
CN16
Front Side USB Connector Pin Definition
Pin Signal Name Description
1 Power Power
2 Power Power
3 USB p2- USB p2-
4 USB p3- USB p3-
5 USB p2+ USB p2+
6 USB p2+ USB p2+
7 GND GND
8 GND GND
9 KEY KEY
10 NC NC
USB1-
V1+ V2+
USB2-
USB2+ USB1+
GND2 GND1
NC USBOC
