24
2. Terminal + and - are only for connecting DC reactor and braking resistor options. Do not
connect it to other devices.
3. Consider the amount of voltage drop when selecting cable sizes. Increase the cable size
when the voltage drop exceeds 2% of the motor rated voltage. The amount of voltage drop
can be calculated using the following formula:
Line drop voltage (V) = 3 × cable resistance (Ω/km) × cable length (m) × current (A) × 10
-3
Table 4.2.2 Cable Size and Tightening Torque (Three-phase 400V & single phase 200V)
Drive
Frame
Terminal
USA
Europe & Asia
Terminal
Screw
Thread
kgf-cm
(in-lbf)
Suggested
Cable Size
AWG, kcmil
Applicable
Cable Size
AWG, kcmil
Suggested
Cable Size
mm2
Applicable
Cable Size
mm2
Frame 1
R, S, T, U, V,
W, PE
12
12 to 18
3.3
3.3 to 0.8
M3
16.1
(14)
Frame 2
R, S, T, U, V,
W, PE
8
8 to 18
8.4
8.4 to 0.8
M4
18.3
(15.9)
