LiteOn EVO600021SD75E20F Quick Start Guide

49
Parameter
Name
Description
Setting Range
L3: Jump Frequency
L3-00
Jump Frequency 1
Sets the Jump frequency range to avoid
operation at the speed causing resonance in the
machinery.
Set L3-00, L3-01 and L3-03 to 0.0 Hz to disable
Jump frequency.
When setting more than 1 Jump frequency,
follow the condition below.
L3-00 ≦ L3-01
Default: 0.0 Hz
Min.: 0.0 Hz
Max.: <5>
L3-01
Jump Frequency 2
L3-03
Jump Frequency
Range
Sets the Jump frequency range to avoid.
Default: 1.0 Hz
Min.: 0.0 Hz
Max.: 20
L4: Frequency Command Hold and Up/Down 2 Command
L4-00
Frequency
Command Hold
Determines whether or not to save the
frequency command or the frequency bias
(Up/Down 2) value when the Stop
command is entered or the power supply is
shut off.
0 ∶ Clear the Up/Down frequency at stop
1 ∶ Save the Up/Down frequency at stop
2 ∶ Accept the Up/Down frequency at stop
Default: 0
Range: 0, 1, 2
L4-01
<4>
Frequency
Command Bias
(Up/Down 2)
Sets the bias used to add to or subtract from the
frequency command by Up/Down 2.
Default:0.00 Hz
Min.: 0.00 Hz
Max.: 99.99 Hz
L4-02
<4>
Frequency
Command Acc./Dec
Setting
(UP2 / DOWN 2)
Sets the acceleration/deceleration times to
increase or decrease the frequency command
bias for Up/Down 2.
0： Current Acc./Dec. Time
1： Non-Current Acc./Dec. Time
Default: 0
Range: 0, 1
L4-03
<4>
Up/Down
Frequency
Command Save
Saves the frequency command from Up/Down 1
or Up/Down 2
Default: 0.00Hz
Min.: 0.00 Hz
Max.: <5>
L4-04
Frequency
Command Save
0: Disabled
1: Enabled
Default: 0
Range 0, 1
L6-00~02
<4>
Offset Frequency
1、2、3
Sets the offset value as a percentage of the
maximum output frequency to add to or subtract
from the frequency command.
Select the offset frequency in E1-□□= 53, 54 and
55 (Offset Frequency 1 to 3).
Default: 0.0%
Min.: -100.0%
Max.: 100.0%
