LIVA Z2 SMALL FORM FACTOR PC USER MANUAL
3
Chapter 1
• 3 x Type-A USB 3.0 ports and 1 x Type-C USB
3.0 port*
• 1 x Power On/Off button
•
1 x Audio combo jack
• 1 x 2-pin Front LED header (optional)
• 1 x 2-pin battery connector
• 1 x 3-pin CPU Cooling Fan connector
• 1 x 4-pin Digital Microphone connector
• 1 x M.2 slot
• 1 x HDD connector (SATA_CONN)
• 1 x LED light
Internal I/O
Connectors &
Headers
Power Supply
• Adapter DA-65C19, 19V, 3.42A, 65W
Dimension
• 132mm x 118mm x 56.4mm
VESA
• 100mm x 100mm
WARNING:
Please realize that there is a certain risk involved with
overclocking, including adjusting the setting in the BIOS, or
using the third-party overclocking tools. Overclocking may
affect your system stability, or even case damage to the
components and devices of your system. It should be done
at your own risk and expense. We are not responsible for
possible damage casesd by overclocking.
*Note:
The Type-C USB 3.0 port of this model is used for data
transmission only, it can not be used for DC-in power
supply and video output.
