LIVA Z2 SMALL FORM FACTOR PC USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. SoC
Intel
®
SoC N4000 / N4100 / N5000
2. BAT Battery
3. BT Battery connector
4. CPU_FAN 3-pin CPU cooling fan connector
5. M2_2230 M.2 slot supports WiFi card
6. SATA_CONN HDD connector
7. LED1 LED light
8. PWR_BTN Power On/Off button
9. F_LED Front LED header (optional)
10. USB3F1~3 Front USB 3.0 ports (Type-A)
11. USB3F4 Front USB 3.0 port (Type-C)
12. DIMM1~2 Dual-channel DDR4 SDRAM SO-DIMM
13. AUDIO_JACK Audio jack
14. DMIC 4-pin Digital microphone connector
