Instruction manual
6
ASSEMBLY DETAILS
1 Set the thermostat support to the tank thanks to the screw 2 Set the feet to the tank thanks to the screw
3 Place the aluminium grease trap on the supports and align the holes in the trap and the supports.
The tank must be filled with water between the MIN and MAX markings; never put water on the heating element or the
thermostat.
4
Place the heating element on its support, making sure that the plastic tab is well inserted in the safety switch. You will hear a
slight "click" that triggers the operation of the heating element when the appliance is in operation and serves as a safety device
in case the barbecue tips over.
5 Position the cooking grid on the heating element, making sure to align it with the holes in the grease trap.
You can only switch on the product if you have correctly assembled.
Screw
Feet
Thermostat support
Grease tray
support
Elément
chauffant
Grill
