LM Technologies LM048 User Manual

FLOW+ MODEM- Tx, Rx, GND,
RTS, CTS
RTS CTS
signals are used
for data ow
control between
host and
adapter, and
NOT transferred
to remote side
wirelessly.
FLOW- MODEML Tx, Rx, GND,
RTS<->CTS,
DTR<->DSR
RTS looped
back to CTS,
DTR looped
back to DSR
FLOW+ MODEML Tx, Rx, GND,
RTS, CTS,
DTR<->DSR
RTS CTS
signals used for
data ow control
between host
and adapter,
and NOT
transferred to
remote side
wirelessly. DTR
looped back
to DSR. This
conguration
is equivalent to
LM048 adapter
running v4.5x
rmware.
16
