LM Technologies LM048 User Manual

3. Package
• Bluetooth serial adapter
• DB9 male to female converter
• USB cable for power supply
• User manual
• Warranty Card
• 2Dbi Antenna (LM058 only)
Optional:
• 9 pin to 25 pin converter
• All in one power supply (UK, EU and US Plug)
4. General Specication
Specication Description
Baud Rate 1.2/2.4/4.8/9.6/19.2/38.4/57.6/115.2/230.4/460.
8/ 921.6 Kbps
Coverage Up to 100 Metres
Connection Point-to-Point (piconet)
Signal TxD, RxD, GND, RTS, CTS, DTR, DSR
RS-232 Interface D_SUB 9-pin female
Standard Bluetooth Specication v2.1+EDR
Frequency 2.400 to 2.4835 GHz
Hopping 1,600/sec, 1MHz channel space
Modulation GFSK-1 Mbps, DQPSK-2 Mbps,
and 8-DPSK-3 Mbps
Tx. power Max. 18 dBm (Class 1)
Rx. Sensitivity -86 dBm typical
Antenna Chip antenna
2
