Lochinvar Crest 5.0 User Manual

17
Installation & Operation Manual
Model
AIR INLET VENT
Input
De-Rate per
25 feet of Vent
Air Intake
Diameter
Air Intake
Min. Length
Air Intake
Max. Length
Vent
Diameter
Vent
Min. Length
Vent
Max. Length
FB 1500 7" 12' 100' 7" 18' 100' 2%
FB 2000 8" 12' 100' 8" 18' 100' 2%
FB 2500 8" 12' 100' 9" 18' 100' 2%
FB 3000 10" 12' 100' 10" 18' 100' 2%
FB 3500 10" 12' 100' 10" 18' 100' 2%
FB 4000 12" 12' 100' 12" 18' 100' 0.5%
FB 5000 14" 12' 100' 14" 18' 100' 0%
Table 2B Direct Vent Minimum / Maximum Allowable Air / Vent Lengths
Model
Vent
Diameter
Vent
Min. Length
Vent
Max. Length
Input De-Rate per
25 feet of Vent
FB 1500 7" 18' 100' 1%
FB 2000 8" 18' 100' 1%
FB 2500 9" 18' 100' 1%
FB 3000 10" 18' 100' 1%
FB 3500 10" 18' 100' 1%
FB 4000 12" 18' 100' 0%
FB 5000 14" 18' 100' 0%
Table 2C Room Air Minimum / Maximum Allowable Air / Vent Lengths
2 General venting (continued)
Table 2A-2 Approved Stainless Steel Terminations and Adapters - Category IV
Model
ProTech Z Flex Heat Fab
Adapter Intake Adapter Intake Adapter Flue Intake
1500
810003977
810003315
810003327
2SVDSA07 2SVEE0790 CCA07MM CCK07TM
9790
9792
2000
810003980
810003357
810003369
2SVDSA08 2SVEE890 CCA08MM CCK08TM
9890
9892
2500
810003982
810003397
810003409
2SVDSA09 2SVEE990 CCA09MM CCK09TM
9890
9992
3000 - 3500
810003984
810003435
810003447
2SVDSA10 2SVEE1090 CCA10MM CCK10TM
91090
91092
4000
810003987
810003476
810003488
2SVDSA12 2SVEE1290 CCA12MM CCK12TM
91290
91292
5000
810003990
810003516
810003528
2SVDSA14 2SVEE1490 CCA14MM CCK14TM
91490
91492
Model
Metal-Fab Security Chimney ICC
Adapter Flue Intake Adapter Flue Intake Adapter Flue Intake
1500
7FCGLCA
MC
6-36"
7FCGSW90 SS7CRESTU
SS0MCU
4" - 24"
SSE7E9OU
SSDOSTAUK
4" - 24"
HE-7DSA-F
HE-7SCR-F
HE-7MC-F
HE-7E90-F
HE-7SCR-F
2000
8FCGLCA
MC
6-36"
8FCGSW90 SS8CRESTU
SS0MCU
4" - 24"
SSE8E9OU
SSDOSTAUK
4" - 24"
HE-8DSA-F
HE-8SCR-F
HE-8MC-F
HE-8E90-F
HE-8SCR-F
2500
8FCGLCA
MC
6-36"
8FCGSW90 SS9CRESTU
SS0MCU
4" - 24"
SSE9E9OU
SDOST90AUK
4" - 10"
HE-9DSA-F
HE-9SCR-F
HE-9MC-F
HE-8E90-F
HE-9SCR-F
3000 - 3500
10FCGLCA
MC
6-36"
10FCGSW90 SS10CRESTU
SS0MCU
4" - 24"
SSE10E9OU
SDOST90AUK
4" - 10"
HE-10DSA-F
HE-10SCR-F
HE-10MC-F
HE-10E90-F
HE-10SCR-F
4000
12FCGLCA
MC
6-36"
12FCGSW90 SS12CRESTU
SS0MCU
4" - 24"
SSE12E9OU HE-12DSA-F
HE-12SCR-F
HE-12MC-F
HE-12E90-F
HE-12SCR-F
5000
14FCGLCA
MC
6-36"
14FCGSW90 SS14CRESTU
SS0MCU
4" - 24"
SSE14E9OU HE-14DSA-F
HE-14SCR-F
HE-14MC-F
HE-14E90-F
HE-14SCR-F
