11
Before placing the
interior assembly
onto the mounting
plate, ensure the
thumb turn is vertical.
Secure the interior
assembly to mounting
plate with 2 screws.
I
2X
I
Torque Blade Thumb turn shaft
Align torque blade with thumb
turn shaft, make sure both are in
the vertical position.
INSTALLING INTERIOR ASSEMBLY (F)
Step 4
continued
RESET
PROGRAM
Place the interior assembly
against the mounting
plate and make sure the
torque blade is inserted
to the thumb turn shaft.
RESET
PROGRAM
RESET
PROGRAM
F
