Exterior
STEP 5: INSTALLING THE LOCK (EXTERIOR)
Install the exterior lock as shown
to the left by aligning the lock
straight and passing the cable and
attached rods through the lockset.
5.2
Pass the square rod (Part C)
through the center of the lockset,
and the round rods through the
sides in their respective holes. The
cable should run undeneath the
lockset.
5.3
Align the lock straight and press
hard (if you use the 3M tape in
step 4.4) to secure the top of the
lock.
5.4
