DKL400UY SLIDING GATE OPERATOR
3
Remote control mode Single Button
Environmental temperature -20°C~+50°C
Main unit dimension
263×240×153mm
MCU logic voltage DC5V
Net weight 21 Kg
Emergency release key in case of power failure
4. Necessary Tools
The following tools may be necessary to install the DKL400UY Gate operator. You will need
screwdrivers, an electric drill, wire cutters and a wire stripper, a socket set, and possibly
access to a welder.
5. Site Preparation
Before you begin the operator installation, the gate should be mounted and moving freely,
there should be little resistance in the movement of the gate. The gate and post must be
suitable for being automated. Check that the structure is sufficiently strong and rigid, and that
its dimensions and weights conform to those listed in the specifications table of this document.
Make sure that the gate is plumb and level. The fence posts must be mounted in concrete.
The DKL400UY is powered by 110V/60Hz AC power, therefore if you have not already done
so; wire a waterproof outlet near the gate following proper safety standards for your area. If
you are not experienced with this type of wiring or if your area requires it, hire a professional
electrician to perform this as well as wire in the DKL400UY in the electrical section. The
DKL400UY requires at least a 10A service. Make sure your electrician takes into account the
voltage drop involved in running many feet of wire to your installation location. If an
insufficient gauge of wire is used, there will be insufficient power at the site to operate the
operator.
Parts List
Item Quantity
Sliding gate operator 1
Operator Base 1
Remote control 2
Master Links 2
Chain 1
Chain Bolts 2
Chain Brackets 2
“U” Bolts for square & round gate frame 4
2 ¾_ (M8x 70mm) Bolts for mounting operator to the base and washers 4
2 ½_ (M8x65mm) Bolts for mounting Magnet brackets and washers 4
3 ¾_Anchor bolts, Anchors, Washers and Nuts (In the same bag with manual
release key)
4
5/8_ (M8x15mm) Socket Head Cap screws for mounting chain box 4
Manual release key 2
Magnet brackets 2
Magnets 2
1m BVR 0.7mm
2
antenna 1
User’s manual 1
