69 -
Technical data
Jack 3.5 mm: ........................................................Headphones 32-2000 ohm
Mini-DIN (AVS) Video IN: ...........................................................Y/C (S-VHS/Hi 8)
........................................................CVBS (VHS/8 mm)
Cinch (yellow) Video IN: ........................................................CVBS (VHS/8 mm)
Cinch (white/red) Audio IN: ..........................................................L (white) / R (red)
2 x IEC socket 75 Ohm/5 V/80 mA: .......................... Antenna/cable/DVB-T/C
(1
2 x F socket 75 Ohm 13/18 V/350 mA: ......................... ANT-SAT DVB-S/S2
(1
Cinch Audio IN max. 2Vrms: ...................................................... Centre
2 x Cinch AUDIO IN1: ......................................................L (white) / R (red)
Jack 3.5 mm AUDIO IN2: ............................................................................L/R
2 x Cinch AUDIO OUT (level configuration-dependent): ..L (white) / R (red)
Cinch COMPONENT IN:.....................................................Cb/Pb signal
Cinch COMPONENT IN:.......................................................Cr/Pr signal
Cinch COMPONENT IN:............................................................ Y signal
Cinch Audio Digital IN (SPDIF): ..........................................Digital audio
Cinch Audio Digital OUT (SPDIF): .......................................Digital audio
SUB-D AUDIO LINK:......................................................... Multi-sound
(1
SUB-D PC IN: ...........................................................PC/STB video signal
SUB-D RS-232C: ............................................................. Serial interface
Mini-DIN SERVICE: ................................................................ Service/L-Link
Mini-DIN CONTROL: .... Rotating stand control (Positioning accuracy 1.5°)
2 x USB USB 2.0: ..................................MP3/WMA/Standard JPEG files
(1
2 x HDMI Digital Video/Audio IN
Type A 19pole Standard 1.3: .................. Digital video and audio
2 x CI-Slot Common Interface: ...................................... Slot for CA module
Ethernet (8P8C) LAN: .............................................................Network interface
(1
(1
Equipment variants and upgrade possibilities, see page 71.
Electrical data
Chassis designation: ........................................................................................... L 2715
Power supply: ........................................................................220 V – 240 V/50–60 Hz
Tuner: .................................................................................. VHF/UHF/cable/hyperband
Range:.......................................................................................... 45 MHz to 860 MHz
Station storage locations incl. AV and radio: ......................................................... 4000
TV standards: .................................................................................. B/G, I, L, D/K, M, N
Colour standard: ........................................ SECAM, PAL, NTSC, NTSC-V, PAL-V (60 Hz)
Sound standard .....................................................Mono/Stereo/2-Ton/Nicam B/G, I, L
Audio output power (music/sine): ................................................ 2 x 40 W / 2 x 20 W
Lower limit frequency of the speakers ................................................................. 90 Hz
Teletext: .......................................................................................... TOP/FLOF Level 2.5
Page memory ........................................................................................................ 2000
Digital teletext (only in UK / IRL with active MHEG-5 software) .......................MHEG-5
Connections (max. equipment)
Mains socket: ................................................................................... Supply voltage
EURO-AV 1 Video IN: ..................................................................Y/C (S-VHS/Hi 8)
...............................................................CVBS (VHS/8 mm)
Video OUT: ............................................................CVBS (VHS/8 mm)
...............................................................Y/C (S-VHS/Hi 8)
Audio IN: .......................................................................................L/R
Audio OUT: ...................................................................................L/R
EURO-AV 2 Video IN: ..................................................................Y/C (S-VHS/Hi 8)
...............................................................CVBS (VHS/8 mm)
.....................................................................................RGB
Video OUT: ............................................................CVBS (VHS/8 mm)
........................................ Y/C, (only with SVHS Link Plus)
Audio IN: .......................................................................................L/R
Audio OUT: ...................................................................................L/R
General data
Type Individual 32 Selection Individual 40 Selection Individual 46 Selection
Article number 69401xxx 67442xxx 67443xxx
Dimensions for device without stand (W x H x D) in cm
Dimensions for device with stand (W x H x D) in cm
81.5 x 57.9 x 9.9
81.5 x 62.8 x 32.0
101.4 x 69.6 x 10.3
101.4 x 74.9 x 38.5
114.0 x 77.2 x 11.5
114.0 x 83.2 x 38.5
Weight for device without stand (approx.) in kg
Weight for device with stand (approx.) in kg
22.4
27.4
28.5
33.5
42.2
47.2
Display technology Full-HD 100Hz LCD technology Full-HD 100Hz LCD technology Full-HD 100Hz LCD technology
Screen diagonal (in cm) / Picture format 80 / 16:9 101 / 16:9 117 / 16:9
Resolution (in pixels) / Picture frequency 1920 x 1080 / 100 Hz 1920 x 1080 / 100 Hz 1920 x 1080 / 100 Hz
Contrast (static / dynamic) 1,300:1 / 10,000:1 2,000:1 / 10,000:1 2,000:1 / 10,000:1
Viewing angle (horizontal / vertical) 178° / 178° 178° / 178° 178° / 178°
Power consumption (EN 62087:2009)
Power consumption "On" (W) without / with DR
+
Power consumption in standby mode (W)
Power consumption when the set is turned off (W)
120 / 125
0.9
0
190 / 195
1.0
0
220 / 225
0.7
0
Ambient temperature (Celsius) 5° – 35°
Relative humidity (non-condensing) 20 – 80%
Air pressure 800 – 1114 hPa (0 – 2000 m above sea level)
