5 -
Connections to rear panel - Xelos A20 / Mimo L20
220 - 240 V ~
Input S-Video
Input Video
Audio inputs
white: left
red: right
Headphone socket
On/Off button
(mains voltage)
AV 1
Socket
Euro-AV 1
AUDIO OUT
L R
Audio outputs
white: left
red: right
ANT VHF/UHF
Antenna socket
TV/FM Radio
Service
Connect
service
AV 2
Socket
Euro-AV 2
