Loewe L 20 DVB-T User Manual

- 6
Connections to rear panel - Xelos A20 DVB-T / Mimo L20 DVB-T
220 - 240 V ~
AV 1
Socket
Euro-AV 1
AUDIO OUT
L R
Audio outputs
white: left
ret: right
ANT VHF/UHF
Antenna socket
TV/FM Radio
Service
Connect
service
DVB-T
Antenna socket
DVB-T
Antenna output
DVB-T tuner
Input S-Video
Input Video
Audio inputs
white: left
red: right
Headphone socket
On/Off button
(mains voltage)
Antenna
connecting
cable
(1
(1
If the set is connected to an antenna system in which the digital (DVB-T) and analogue antenna signals are distributed together house internally, a connecting cable
must be plugged as illustrated. The antenne bridge then makes the connection with the analogue tuner.
In all other cases, connect your antennal(s) as described on page 9.
