Off
Cold
Cold
Cold
30
How to connect from the left side
~80cm
~90cm
~85cm ~135cm
min. 60cm
max. 100cm
~40cm
~130cm
How to connect from the right side
Levelling the Washing Machine
There are 4 levelling feet on the underside. They must be adjusted to make sure the washing machine
is level.
1. On each foot, loosen the lock ring by turning it clockwise.
2. Adjust all four feet by rotating each upwards or downwards.
3. Use a spirit level to ensure the washing machine is level.
4. Tighten each lock ring by turning them anti-clockwise (towards
the washing machine body).
Ensure all four lock rings are tightened securely. Check the feet are
still bolted to the washing machine - if they’re unbolted, the washing machine will
move around.
Water Supply Hose
Points to remember
• Follow the instructions in this section to avoid water leaks.
• Don’t connect the hose to a combination tap.
• Don’t twist, squash, modify or cut the hose.
• This machine is designed to connect to the cold water supply. Do not connect to the hot water
supply.
• Use only the new water supply hose supplied. Old hose sets should not be reused.
Hose and Cable Lengths
Plastic Nut
Foot
* All images are for indication only; please refer to your individual unit for actual item.
INSTALLATION
8
