Connecting the Water Supply Hose
1. To prevent leakage from the connection joints,
ensure the rubber washer seals are fitted to
each end of the water supply hose. Do not use
without the seals in place.
2. Fit the straight end of the water supply hose
to the cold water tap.
3. Connect the angled end of the white headed hose to the
water inlet valve on the machine. Hand tighten the plastic
parts of the connections. If you are unsure, please call a
qualified plumber for safer connections.
4. Open the tap slowly and check that there are no leaks around
the connection joints.
U-Shape Holder
Draining to a wash-basin Draining to a drain hose
Water Drain Hose
Points to remember:
• Don’t twist, pull out or bend the drain hose.
• Your washing machine should be no more than 85cm from the drain outlet.
• The water drain hose should be mounted at a height of minimum 60 cm, maximum 100 cm from
the ground.
Draining to a sink or wash-basin
• Secure the drain hose in position, so it can’t drop out of the basin.
• Don’t block the basin’s drain outlet, and make sure that the drainage through it is sufficient to
prevent overflowing.
• Don’t let the tip of the drain hose dip into the drained water, as this can cause the water to flow
back into the washing machine.
Cold water inlet
(White lter valve)
* All images are for indication only; please refer to your individual unit for actual item.
