Logik L614WD13

SERVICE MANUAL
Front Load Washing Machine
03D Series
29
Pilkor Electronics
Co.Ltd
PCX2 337J60334
X2,0.0047UF
275VAC
IEC/EN132400
ENEC
Xiamen Faratronic
Co.,Ltd.
MKP61 X2,0.0047UF
275VAC
IEC/EN132400
VDE
EPCOS(Zhuhai
FTZ)Co., Ltd
B32921C3473K2
89
X2,0.0047UF
305VAC
IEC/EN132400
VDE
Okaya electric
industries Co., Ltd.
LE104-M
X2,0.0047UF
275VAC
IEC/EN132400
ENEC
Nistronics (Jiangxi)
Co.,Ltd
MPRC
0275K472000000
35
X2,0.0047UF
275VAC
IEC/EN132400
VDE
Jimson Electronics
(Xiamen)Co.,Ltd
MKP472K/275VA
C P10
X2,0.0047UF
275VAC
IEC/EN132400
VDE
4.X2Capacitor
CX1
Ultra Tech Xiphi
Enterprise Co.Ltd
HQX472K275F15
SNY
X2,0.0047UF
275VAC
IEC/EN132400
VDE
Xiamen Hongfa
Electroacoustic
Co.,Ltd.
JZC-32F/012-HS
5A 250VAC
5A 30VDC
IEC/EN61810
VDE
Tyco Electronics
(shenzhen) Co.,
Ltd
OJE-SH-112DM
5A/250VAC
IEC/EN61810
VDE
Anhui Mingguang
Life Electronic
Co.,Ltd
BJ-SS-112DM
10A125VAC
5A250VAC/30VDC
IEC/EN61810
TUV
5. Relay K1
Xiamen Song
Chuan Precision
Co., LTD.
307-1AH-C
5A/250VAC
IEC/EN61810
TUV
Anhui Mingguang
Life Electronic
Co.,Ltd
BRD-SS-112L
12A/7A250VAC
15A125VAC
IEC/EN61810
TUV
Xiamen Song
Chuan Precision
Co., LTD.
812H-1C-V
10A/8A/277VAC
IEC/EN61810
VDE
Omron Electronic
Components
(Shenzhen) Ltd.
G5LA-14
10A/250VAC,5A/2
50VAC
IEC/EN61810
VDE
Relay K2,K3,K4
Xiamen Hongfa
Electroacoustic
Co.,Ltd.
HF3FD-012-ZSTF
(245)
10A/250VAC
IEC/EN61810
VDE
6. Varistor RV1ˈ
EPCOS (Zhuhai
FTZ) Co., Ltd.
B72214S2351K5
02
Imax˖8000A
V1mA˖560V
IEC/EN61051
VDE
EPCOS (Zhuhai
FTZ) Co., Ltd.
B72207S2271K1
01
Imax˖1200A
V1mA˖430V
IEC/EN61051
VDE
7.Varistor RV2ˈRV3
Thinking
(Changzhou)
Electronic Co Ltd
TVR07431
Imax ˖ 1200A
V1mA˖430V
IEC/EN61051
VDE
