Logik L614WD13

SERVICE MANUAL
Front Load Washing Machine
03D Series
30
1.PCB ASSEMBLY
˄drive board˅
Haier Interlligent
Electronics Co.Ltd.
0021800052
220-240V
50Hz/60Hz
/
Test with
appliance
Changzhou
Haihong
Electronics Co.Ltd.
KB-5150 CEM-1 E166702
UL
Changzhou
Haihong
Electronics Co.Ltd.
ZD-95GF CEM-1 E166702
UL
HT Circuits
(Qingdao) Co.,Ltd.
S3155 CEM-1 E56334
UL
HT Circuits
(Qingdao) Co.,Ltd.
S3116 CEM-1 E56334
UL
HT
Circuits(Qingdao)
Co., Ltd.
KB5150 CEM-1 E56334
UL
HT
Circuits(Qingdao)
Co., Ltd.
KB5150 CEM-1 E56334
UL
HT
Circuits(Qingdao)
Co., Ltd.
ZD-95(G)F CEM-1 E56334
UL
2.PCB
HT
Circuits(Qingdao)
Co., Ltd.
DS7106 CEM-1 E56334
UL
EPCOS Electronic
Components S.A. .
B3292#
X2,0.047UF
305VAC
IEC/EN132400 VDE
Okaya electric
industries Co., Ltd.
LE473M
X2,0.047UF
275VAC
IEC/EN132400 ENEC
Pilkor Electronics
Co.Ltd
PCX2
X2,0.047UF
275VAC
IEC/EN132400 ENEC
Nistronics (Jiangxi)
Co.,Ltd
MPR
X2,0.047UF
275VAC
IEC/EN132400 VDE
ultra tech xiphi
enterprise co., ltd
HQX
X2,0.047UF
275VAC
IEC/EN132400 VDE
Xiamen Faratronic
Co.,Ltd.
MKP61
X2,0.047UF
275VAC
IEC/EN132400 VDE
3. C9
Jimson Electronics
(Xiamen)Co.,Ltd
MKP
X2,0.047UF
275VAC
IEC/EN132400 VDE
OMRON  G5LA-1
NO:10A/250VAC,N
C:5A/250VAC
IEC/EN61810
VDE
Xiamen Song
Chuan Precision
Co., Ltd.
812H
NO/NC:10A/8A/277
VAC
IEC/EN61810
VDE
5. Relay K1,K2,K3
Xiamen Hongfa
Electroacoustic
Co.,Ltd.
HF3FD-012-ZSTF
(245)
10A/250VAC
IEC/EN61810
VDE
