3. Carefully remove the fridge and freezer
doors by pulling the middle hinge
towards you to release the hinge, the top
door may need lifting to allow this. Lower
the top door off the top hinge pin. Lift
the bottom door off the bottom hinge
pin.
4. Tip and support the unit (be careful not
to damage the cooling circuit) to allow
you to get your hands underneath the
kickplate. Remove the kick plate by
pulling the bottom down and forward off
the fixing clips.
5. Unscrew the bottom hinge fixing screws
and remove it. Remove the plastic
washer.
6. Unscrew the pin of the bottom hinge
from Hole 1, rotate the bottom hinge 90°
and screw the pin into Hole 2.
7. Remove the tape covering the fixing
holes on the unit and the fixing holes
of the bottom hinge. Screw the bottom
hinge to the bottom left side of the unit.
Replace the plastic washer removed
above.
1
2
Hole
Hole
