Table for the Choice of the Injectors
Burner Injector Values
According To The Gas Type
LPG Natural Gas
G 30-30
mBar
G 20-20
mBar
Large Burner (Fast)
Injector mm 0.850 1.150
Gas Flow
(15°C and 1013mbar)
218.13 gr/h 285.70 lt/h
Power kW 3.000 3.000
Standard Burner
Injector mm 0.650 0.970
Gas Flow
(15°C and 1013mbar)
127.25 gr/h 166.66 lt/h
Power kW 1.750 1.750
Small Burner (Simmer)
Injector mm 0.500 0.720
Gas Flow
(15°C and 1013mbar)
72.71 gr/h 95.24 lt/h
Power kW 1.000 1.000
Grill Burner
Injector mm 0.700 1.100
Gas Flow
(15°C and 1013mbar)
145.40 gr/h 209.50 lt/h
Power kW 2.000 2.200
Main Oven Burner
Injector mm 0.750 1.150
Gas Flow
(15°C and 1013mbar)
174.50 gr/h 228.60 lt/h
Power kW 2.400 2.400
• All intervention regarding installation maintenance and conversion of the appliance must be
fulfilled with original factory parts.
• The manufacturer declines any liability if these correct parts are not used.
