INSTALLATION
7
<5kg
Do not move the unit while the
levelling feet are extended.
6. Position the dishwasher next to a water tap
and a drain. Ensure the water inlet and drain
hoses are not kinked or squashed. The unit
must not stand on the mains cable.
7. Good levelling is essential for correct closure
and sealing of the door. When the unit is
correctly levelled, the door should not catch
the inner liner on either side of the cabinet.
Adjust the levelling feet to obtain the
optimum levelling of the unit.
8. Tape the supplied Door Template to the
dishwasher door. Ensure the aesthetic
door weight is a minimum of 3kg and a
maximum of 5kg. Make sure the top of the
template is at the top of the door. Drill the
required holes following the depth and
diameter shown on the Door Template.
