INSTALLATION
2. Rotate the door hinges and place them
diagonally on the opposite corner of the
cabinet as shown in the diagram. Secure
them with the screws.
3. Place the door back and screw the door hinges. With the door closed, check that the door
is aligned horizontally and vertically and that the seals are closed on all sides before nally
tightening the hinges. Re-adjust the levelling feet as needed.
4. Insert the screw hole covers to the right side.
• Do not lay the unit at as this may damage the coolant system.
• During door reversal, when swapping the position of the bottom hinge or
adjusting the levelling feet, tilt the unit. Do not lay the unit at.
