Logitech RALLY PLUS Implementation Guide

LOGITECH RALLY AND RALLY PLUS IMPLEMENTATION GUIDE
p13
 
 

 
 




Logitech RALLY PLUS Specifications

General

Pan range	-90 - 90 °
Pan speed	70 °/sec
PTZ control	Yes
Product type	Group video conferencing system
Product color	Graphite
Tilt angle range	-90 - 50 °
Number of persons	- person(s)
Megapixel	- MP
Sensor type	-
Digital zoom	3 x
Optical zoom	5 x
Focus adjustment	Auto
Image sensor size	- \
Horizontal field of view	260 °
Number of camera presets	1
Field of view (FOV) angle	90 °
Maximum frame rate	60 fps
Supported video modes	480p, 720p, 900p, 1080p, 1440p, 2160p
Maximum video resolution	- pixels
Microphone frequency	90 - 16000 Hz
Microphone sensitivity	-27 dB
Microphone direction type	Omnidirectional
Microphone pick-up range	4.5 m
Telepresence	No
Cable lock slot type	Kensington
USB connector type	USB Type-A, USB Type-B, USB Type-C
HDMI ports quantity	4
USB 2.0 ports quantity	5
Ethernet LAN (RJ-45) ports	2
Power source type	AC

Weight and Dimensions

Camera dimensions (WxDxH)	152 x 152 x 182.5 mm
Speaker dimensions (W x D x H)	449 x 103 x 80 mm
Microphone dimensions (W x H x D)	102 x 102 x 21 mm
Interface module dimensions (W x D x H)	206 x 179 x 40 mm
