Audio Engine - AE32 Specifications
Audio Processor
General 32 bit floating point processing, 24 bit mantissa
Lone SHARC™ card: 1 Analog Devices’ SHARC™ DSP
Full House card: 3 Analog Devices’ SHARC™ DSPs and
DRAM interface
Internal sampling rate User selectable 32k, 44.1k or 48k
External clock input AES/EBU, S/PDIF; 24kHz to 56kHz
Latency Constant from all inputs to all outputs.
Dimensions Actual - 19“ w x 15” d x 12 ¼” h (7RU)
(48 ¼ cm w x 38 ¼ cm d x 31 cm h)
Shipped - 24“ w x 19 ½” d x 18” h
(61 cm w x 49 ½ d x 45 ¾ h)
Weight Fully loaded - 44 lbs.
Machine control
Inputs +5 to ground
Outputs Dry contact relays
Functionality User definable.
Audio I/O
Number of I/O cards Up to 8; either analog or digital. Each card has 8 inputs and outputs.
Software configurable as to mono/stereo per c hannel (a card can be 8
mono, 4 stereo, 1 multi track 3 stereo, 2 mono, 2 stereo, 4 mono , 1
stereo, 6 mono, etc.) Definitions can span more than one card
Channel inputs Up to 64
Channel outputs Up to 64
Number of busses Up to 64; the same as the number of outputs. Busses are user defined.
Connectors DB 25; fan out to XLR or punch block (optional)
Feature Auto calibration - provide a 0 reference tone and the Audio
Engine will calibrate input gain
24 Appendix
