1.11 Conformal coat over electronics
Procedure:
1. Apply conformal coat to area shown below using dispensing robot.
2. Allow to dry for 24 hours before proceeding to next step.
DO NOT coat the battery pads!!!
Conformal coat area
marked in red
DO NOT coat the Crystal, body,
legs or pads.
DO NOT coat C2 or C3 !!!
