Instructions for use Lojer Modux nursing bed / Version 2.5
Copyright © Lojer Oy, 2022 26
Installation and use of accessories
This section describes how to install and use nursing bed accessories. The
accessories are supplied separately.
Use only bed’s accessories approved by the manufacturer!
When transporting the bed, it is recommended that all protruding
accessories are removed to minimise the risk of collisions.
When using other than bed`s accessories make sure that accessories
used doesn`t generate danger to patient or for usability of the bed (for
example squeezing gaps).
7.1 Lifting pole (101912)
The patient can use the lifting pole as an aid to change position or to get up
from the bed.
Mount the pole into the sleeve by the headboard in such a way that it cannot
move sideways. The pole can be mounted on the left or the right side of the
bed.
The pole is mounted correctly when the handle is hanging above the sleeping
surface and the pole does not move sideways.
Maximum load (SWL) for the lifting pole is 75 kg.
Danger of crushing fingers between the lifting pole and the end of the
bed. Exercise caution when installing the pole.
Before the lifting pole is used, make sure that it is correctly positioned
above the bed and locked so that it cannot move sideways.
Check that there is space above the bed. When you raise the bed the
lifting pole rises with it.
7.2 Lift support (71100KP)
The lift support is used as an aid for the patient when getting in and out of the
bed. The maximum load (SWL) for the lift support is 50 kg.
Remove the lift support handle or raise the side rails for a period when
patient is sleeping.
Never turn the handle of the support inwards to the bed.
There is a danger of crushing when adjusting the lift support and the
back section.
There is a risk of crushing when using the side rails and the lift support
simultaneously.
