9.5 Functional testing and inspection
Carry out functional testing without load and with normal patient load (approx.
60–100 kg). Test the mechanism’s movement and stopping in the extreme
positions. Observe any unusual sounds, vibrations, etc. Also pay attention to
stability, unusual wobbling of mechanisms, looseness, etc. Perform the
following actions for the listed items:
 motors, lifting and sleeping surface adjustment movements, load testing
 the hand-held controller and its functions
 nurse control panel (optional), test the locking functionality
 rail functionality, locking in top position, space between the rails
 accessories, mounting and operation
 if there are unusual sounds, determine the source of the sound
 e.g. if there is an unusually loud creaking sound when adjusting the back
section, check the bearings and the motor fastening pins and clearance,
lubricate the pins/bearings and replace when necessary
Check the operation, locking and sturdiness of the following:
 wheels with brakes
 wheel bearings
 brake pedal
 check the functional measurements of the rails in accordance with image
49.
Image 49. Siderail dimension in accordance with standard 60601-2-52.
 Perform the measurement on the siderails while locked in their top position.
Perform the check on both sides of the bed.
less than 60 mm
less than 60 mm or over
318 mm
Also check the siderails height spacing.
Space between the sleeping surface and
the lower siderail max. 120 mm. Similarly,
space between the upper and lower
siderails, centre of rail max. 120 mm.
A gap between siderail -wood and
beds’ end must be less than 60 mm
(Note: applies also to gaps between
raised siderail and beds’ ends)
Height (approx. 360mm) -
220mm = used mattress
height (130
mm
)
